BOPET thermal transfer film

Product Description：
BOPET thermal transfer film is a thermal transfer printing functional film. It can be processed by a transfer machine to transfer the pre-printed pattern on the surface of the BOPET thermal transfer film to the surface of the substrate (touch or curved surface) and form it. After the pattern is integrated with the product surface, the transfer film falls off.
Product Type：
BOPET thermal transfer film
Application Scope：
1. In-mold decoration (IMD);
2. Used in aluminum spray transfer paper and gold and silver cardboard.

Product name:BOPET heat transfer film

Product features

1. Good surface flatness, good thermal stability and high tensile strength;

2. Mature technology and excellent processing performance;

3. Depending on the quality requirements of the final product, it can be reused once or multiple times.

Corona surface: no corona treatment.

Typical physical properties of products

Performance indicators Properties			unit Unit	Test results Test result	Testing standards Test standard
1	Thickness		μm	15~25	ASTM-D374
2	tensile strength Tensile Strength	Longitudinal MD	MPa	≥ 200	ASTM-D882
2	tensile strength Tensile Strength	Horizontal TD	MPa	≥ 200	ASTM-D882
3	Elongation at break Elongation At Break	Longitudinal MD	%	≤ 150	ASTM-D882
3	Elongation at break Elongation At Break	Horizontal TD	%	≤ 150	ASTM-D882
4	Haze		%	≤ 5.0	ASTM-D1003
5	Thermal shrinkage Thermal Shrinkage	Longitudinal MD	%	≤ 3	ASTM-D1204
5	Thermal shrinkage Thermal Shrinkage	Horizontal TD	%	≤ 3	ASTM-D1204
6	GlossinessGloss		%	≥ 90	ASTM-D2457

Note: Special requirements can be negotiated separately.
